Description
The Lenovo ThinkSystem P5520 3.84TB Read Intensive NVMe SSD delivers high-performance enterprise storage for read-intensive and general-purpose data center workloads. Featuring a PCIe 4.0 x4 NVMe interface, this 2.5-inch U.2 hot-swap drive provides high throughput, low latency, and efficient I/O performance for compatible Lenovo ThinkSystem servers.
Built with TLC 3D NAND technology, the P5520 supports TCG Opal self-encrypting drive (SED) security, end-to-end data-path protection, enhanced power-loss protection, thermal monitoring, and SMART health reporting. The 3.84TB model is rated for 1 DWPD over five years with an endurance of 7.0 PB total bytes written, making it well suited for enterprise applications where read performance, reliability, and data security are priorities.
With performance of up to 1,000,000 random read IOPS, 200,000 random write IOPS, 6.7 GB/s sequential reads, and 3.6 GB/s sequential writes, the P5520 provides the bandwidth needed for demanding server and data center environments.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Lenovo |
| Product Family | ThinkSystem |
| Series | P5520 |
| SKU / Part Number | 4XB7A13942 |
| Feature Code | BMGE |
| Supplier Part Number | SSDPF2KX038T1O |
| Drive Type | Solid State Drive (SSD) |
| Capacity | 3.84TB |
| Form Factor | 2.5-inch |
| Drive Interface | U.2 |
| Host Interface | PCIe 4.0 x4 |
| Protocol | NVMe |
| Hot-Swap | Yes |
| Workload Type | Read Intensive |
| NAND Technology | TLC 3D NAND |
| SED Encryption | TCG Opal |
| Endurance | 1 DWPD over 5 years |
| Total Bytes Written | 7.0 PB |
| Random Read Performance | Up to 1,000,000 IOPS |
| Random Write Performance | Up to 200,000 IOPS |
| Sequential Read | Up to 6.7 GB/s |
| Sequential Write | Up to 3.6 GB/s |
| Sequential Read Latency | 10 µs |
| Sequential Write Latency | 13 µs |
| Random Read Latency | 75 µs |
| Random Write Latency | 15 µs |
| MTBF | 2,000,000 hours |
| Average Active Read Power | 15 W |
| Average Active Write Power | 15 W |
| Security | Self-Encrypting Drive (SED) |
| Additional Features | Power-loss protection, thermal monitoring, SMART health reporting |
| Application | Enterprise servers and read-intensive data center workloads |
