Description
- Wireless presentation for enhanced efficiency
- Single USB-C cable for 65W power delivery
- 24/7 video playback for continuous communication
- Remote device management with myViewBoard Manager
- ProAV compatibility with Crestron, Extron, and AMX
- Portrait-oriented display for impactful brand signage
OVERVIEW
With stunning 4K Ultra HD resolution, high brightness, and landscape and portrait modes, the CDE30 Series offers continuous and sustainable 24/7 display for both corporate and campus communication. Purpose-engineered for ease of use, the display is equipped with a Quad Core SoC to run multiple operations seamlessly, and its USB-C one-cable solution sorts for effortless connection with external devices. Designed for easy-to-operate continuous multimedia playback, the CDE30 Series offers cable-free screen casting and screen sharing through myViewBoard Display and ViewBoard Cast, which also supports Airplay and Chromecast. Remote management via the intuitive myViewBoard Manager makes changing content, broadcasting, and software updates a breeze. Available in 6 sizes ranging from 43" to 98", complete with daisy-chain compatibility, the CDE30 Series meets and exceeds the communication needs of any campus or corporate spaces.
SPECIFICATIONS
-
Display
Panel Size: 75"
Type/ Tech: TFT LCD Module. ADS type, DLED backlight
Display Area (mm): 1649.664 (H) ×927.936 (V) (75” diagonal)
Native Resolution: 3840 x 2160
Aspect Ratio: 16:9
Colors: 1.07G (8bits + FRC-)
Brightness: 450 nits (typ.)
Contrast Ratio: 1200:1 (typ.), 5000:1 (DCR enabled)
Response Time: 8ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 50,000 hours
Surface Treatment: Anti-Glaire, 3H hardness, Haze 25%
Bezel: 14.7/14.7/14.7/14.7 mm (L/R/T/B)
Orientation: Landscape & Portrait
-
Platform
Processor: Quad-core ARM Cortex A55
RAM: 4GB
Storage: 32GB
-
INPUT
HDMI: 2.1x3 ( 3840x2160 @60Hz, HDMI 1 support ARC)
RS-232: x 1
OPS Slot: x 1
WiFi Slot: x 1
-
OUTPUT
HDMI: 2.0 x1 ( 3840x2160 @60Hz )
SPDIF: x 1
-
LAN
RJ45: x 1
-
USB
Type A: 2.0 x 1, 3.0 x 1
Type C: x1 ( (DP1.2, PD 65W, USB2.0, 100M ethernet)
-
SPEAKERS
10W x2
-
Embedded OS
Android 11
-
POWER
Voltage: 100-240 VAC +/- 10%
Consumption: 126 W(typ.) < 0.5W(off)
-
OPERATING CONDITIONS
Temperature (º C): 0 to 40℃
Humidity: 10%-90% RH
-
Operating Hours
7/24
-
DIMENSIONS (W x H x D)
Physical (inch / mm): 66.36 x 37.94 x 3.21in/ 1685.6 x 963.7 x 81.6mm
Packaging (inch / mm): 73.35 x 42.91 x 8.86 in./1863 x 1090 x 225 mm
-
WEIGHT
Net (lb / kg): 76.39 lbs/34.65 kg
Gross (lb / kg): 106.15 lbs/48.15 kg
-
REGULATIONS
cTUVus, FCC/ICES003, Energy star 8.0, EPEAT, Mexico NOM , Mexico Energy, EMC/CE , CB, EAC, UkrSEPRO, RCM, LBL, Flicker free, Green BOM, RoHS , ErP, REACH, SCIP, WEEE , Annex I, Annex II, TPCH , Packing waste, CA65
-
PACKAGE CONTENTS
1. Remote Control with batteries
2. Quick Start Guide
3. Power Cables
4. HDMI cable
5. USB-C cable
6. Wall Mount Screw x 4
7. RS232 adapter
8. Compliance statement
