Mellanox Half-Width 16-Port Non-Blocking 100GbE Open Ethernet Switch System

Mellanox Half-Width 16-Port Non-Blocking 100GbE Open Ethernet Switch System
The SN2100 switch provides a high density, side-by-side 100GbE switching solution which scales up to 64 25GbE ports in 1RU for the growing demands of today's database, storage, data centers environments.

The SN2100 switch is an ideal spine and top of rack (ToR) solution, allowing maximum flexibility, with port speeds spanning from 10Gb/s to 100 Gb/s per port and port density that enables full rack connectivity to any server at any speed. The uplink ports allow a variety of blocking ratios that suit any application requirement.

Powered by the Spectrum ASIC and packed with 16 ports running at 100GbE, the SN2100 carries a whopping switching capacity of 3.2Tb/s with a landmark 4.8Bpps processing capacity in a compact 1RU form factor.

• Lowest Power: Under 6 watts per port


• Lowest Latency: 300nsec for 100GbE port-to-port, Flat latency across L2 and L3 forwarding


• High Density: 16 ports of 40/56/100GbE in 1RU, Up to 64 ports of 10/25GbE, Up to 32 ports of 50GbE


• Wire Speed Switching: 3.2Tb/s, 2.38B packets-per-second
